6 TECHNICAL DATA
Operating conditions:
Operating temperature 0..+55°C
Protection class IP 65 according to EN 60529
Conformity with following standards:
CE Mark Conformity with regard to the EMC
directive 89/336/EWG (only for correctly
connected cable and/or plug and
socket)
Mechanical data:
Dimensions see data sheet
Top
Control
housing material External PPE/PA, PSU; Internal PA 6
Sealing material Top
Control
NBR
Pneumatic data:
Control medium: Instrument air,
Kl. 3 according to DIN ISO 8573-1
Pressure dew point: -20°C
Oil content: max. 1 mg/m³
Dust content: 5µm filtered
Temperature range of
the compressed air: 0..+55°C
Pressure range: 2..10 bar
Pressure output of the 40 l
N
/min (for aeration and ventilation)
control valve: (Q
Nn
value - according to definition for
pressure fall from 7 to 6 abs.)
Connections: 1/8’’ inner thread G / NPT / RC
