40
Top
Control
ON/OFF
english
Electrical data without bus control
Connections PG11 glands with screw terminal
Electrical supply • 24 V DC ± 10 %
• Residual ripple 10% for inductive
switches
• 110 V AC ± 10 %
• 230 V AC ± 10 %
Power consumption Voltage single double
working working
24 V 2 W 4 W
110 V 3 W 6 W
230 V 3 W 6 W
Electrical data for the variants with bus control (AS interface)
Connections M12 round connector or
PG11 gland with screw terminals
Power supply 29,5..31,6 V DC (according to
specification)
max. current consumption
Current consumption
in normal operation
after power reduction
Outputs
max. switching power 2 x 2 W via AS interface
Watchdog function integrated
Inputs
Power supply for sensors via the AS inteface
Sensor supply voltage 24 V ± 10%
Current consumption max. 20 mA
