REPAIR PARTS FOR BARE BOILER ASSEMBLY
ITEM
NO.
DESCRIPTION
BOILER SIZE / QUANTITY
PART NO.
V903A V904A V905A V906A V907A V908A V909A V910A V911A V912A
1 Front Section 1 1 1 1 1 1 1 1 1 1 7172936
2
“C” Center Section 1 2 3 4 5 6 7 8 9 10 7172940
3 Optional - “CT” Center Section w/Tankless Heater
Opening -
Max. No. of Heaters -
(“CT” Replaces “C” Center Section)
1 1 1 2 2 2 3 3 3 4 7172941
4 “CX” Center Section with 4” Supply Tapping - Steam
Boiler Only
1 7172942
5 Back Section 1 1 1 1 1 1 1 1 1 1 7172938
6 Target Wall (V903A only) 1 6202901
Silastic, 500°F, 10 oz. Tube 2 3 3 4 5 6 6 7 8 9 9056060
7 7” Cast Iron Slip Nipple 2 3 4 5 6 7 8 9 10 11 7066004
8 3” Cast Iron Slip Nipple 4 6 8 10 12 14 16 18 20 22 7066002
Nipple Lubricant, Loctite® #592, 50 ml 1 2 2 3 3 4 4 5 5 6 8056254
Nipple Gauge, 3” & 7” 1 1 1 1
1 1 1 1 1 1 806600023
9 5/8” - 11 x 9-3/4”” Lg. Tie Rod 8 12 16 20 24 28 32 36 40 44 80861101
10 Formed Steel Flue Cover Plate (with insulation) 2 3 4 5 6 7 8 9 10 11 6112901
11 Tankless Heater/Cover Plate Gasket (One Required for each “CT” Section) 8036058
12A V9-2 Tankless Heater Assembly
(Includes gasket & mounting hdwe)
(One Required for each “CT” Section) 6032901
- OR - 60429048
12B Blank Heater Cover Plate (One Required for each “CT” Section) 7036020
13 Tankless Heater /Cover Plate Mounting Hardware,
3/8” -17-7/8” Lg.
(Eight Required for each “CT” Section) 80361337
Cap Screw, SA-307B (ASME Code Mat’l)
14 Canopy Assemblies
1 6112903001
1 6112904001
1 6112905001
1 6112906001
1 6112907001
1 6112908001
1 6112909001
1 6112910001
1 6112911001
1 6112912001
15 Cerafelt Gasket, 1/2” x 2” Wide x L.F. 5 6 7 8 9 10 11 12 13 14 9206003
16 Canopy Mounting Bracket (Front) 2 2 2 2 2 2 2 2 2 2 71129002
17 Canopy Intermediate Hold-Down Bracket 2 2 2 4 4 4 71129007
18 Canopy ‘J’ Bolt, 5/16 - 18 x 7-3/4 Lg. 1 1 1 2 2 2 80861679
19 Adhesive Fiber Gasket, 1/8” x 1” Wide x L.F. 10 10 10 10 10 10.5 10.5 10.5 11 11 9206032
20A
Rear Flue Outlet Assembly, 7” Dia. Collar 1 1 61129003
Rear Flue Outlet Assembly, 8” Dia. Collar 1 1 1 61129042
Rear Flue Outlet Assembly, 10” Dia. Collar 1 1 1 61129062
Rear Flue Outlet Assembly, 12” Dia. Collar 1 1 61129092
- OR -
20B Rear Flue Outlet Cover 1 1 1 1 1 1 1 1 1 1 61129001
21A
Top Flue Outlet Assembly, 7” Dia. Collar 1 1
Top Flue Outlet Assembly, 8” Dia. Collar 1 1 1 6112627
Top Flue Outlet Assembly, 10” Dia. Collar 1 1 1 6112628
Top Flue Outlet Assembly, 12” Dia. Collar 1 1 6112629
- OR -
