Burnham V9A Series User Manual

61
ITEM
NO.
DESCRIPTION
BOILER SIZE / QUANTITY
PART NO.
V903A V904A V905A V906A V907A V908A V909A V910A V911A V912A
21B Top Outlet Canopy Cover, 7 & 8” Dia. Opening 1 1 1 1 1 7112638
Top Outlet Canopy Cover, 10” Dia. Opening 1 1 1 7112639
Top Outlet Canopy Cover, 12” Dia. Opening 1 1 7112640
22 Burner Mounting Plate Assemblies (Incl. Items 23-27 & Mtg. Hdwe)
8” Extended Burner Mounting Plate Assembly 1 1 1 6022909
- OR -
4” Standard Burner Mounting Plate Assembly 1 1 1 1 1 1 1 6022908
23 Burner Mounting Plate:
8” Extended C.I. Burner Mounting Plate (Machined & Painted) 1 1 1 7172913
- OR -
4” Extended C.I. Burner Mounting Plate (Machined & Painted) 1 1 1 1 1 1 1 7172912
24 Shutter Door Assembly Parts:
Handle Knob 1 1 1 1 1 1 1 1 1 1 8026036
Shutter Handle 1 1 1 1 1 1 1 1 1 1 8026033
Shutter Spring 1 1 1 1 1 1 1 1 1 1 8026034
Observation Port Shutter (Machined & Painted) 1 1 1 1 1 1 1 1 1 1 70260051
Spring Pin 1 1 1 1 1 1 1 1 1 1 8026035
25 Observation Port Assembly Parts:
Observation Port Cover (Machined & Painted) 1 1 1
1 1 1 1 1 1 1 70260041
Observation Port Outer Gasket 1 1 1 1 1 1 1 1 1 1 8206001
Observation Port Glass 1 1 1 1 1 1 1 1 1 1 8026032
Observation Port Inner Gasket 1 1 1 1 1 1 1 1 1 1 8206002
26 8” Extended Burner Mounting Plate Insulation 1 1 1 8202905
-OR -
4” Standard Burner Mounting Plate Insulation 1 1 1 1 1 1 1 1 8202904
27 3/16” Dia. Rope Gasket 1 1 1 1 1 1 1 1 1 1 72026021
28 Burner Adapter Plate Assembly w/Gasket and Hardware:
Beckett (“CF”) BAP No. 920, 4-3/4” Dia. Hole 1 1 602292201
Beckett (“CF”) BAP No. 921, 6-1/8” Dia. Hole 1 1 602292211
Beckett (“CF”) BAP No. 922, 6-3/4” Dia. Hole 1 1 1 1 1 1 602292221
- OR -
Power Flame (“C”) BAP No. 940 , 7-1/2” Dia. Hole 1 1 1 1 602292401
Power Flame (“C”) BAP No. 941 , 9” Dia. Hole 1 1 1 1 1 1 602292411
- OR -
Power Flame (“JR”) BAP No. 945 , 6-3/8” Dia. Hole 1 1 1 1 602292451
Power Flame (“JR”) BAP No. 946 , 8-3/8” Dia. Hole 1 1 1 602292461
- OR -
Webster BAP No. 960, 6-5/8” Dia. Hole 1 1 1 1 1 1 1 1 1 602229260
Burner Adapter Plate Gasket Only 1 1
1 1 1 1 1 1 1 1 8202906
29
Rear Observation Port Cover Assembly
(Incl. Gasket & Mtg. Hdwe)
1 1 1 1 1 1 1 1 1 1 609600011
Gasket Only 1 1 1 1 1 1 1 1 1 1 9206060
30 3/8” Diameter Rope Gasket 2 3 4 5 6 7 8 9 10 11 7202948
Press Relief Door Assembly (not shown) 1 1 1 1 1 1 1 1 1 1 61125251
Press Relief Door Gasket (not shown) 1 1 1 1 1 1 1 1 1 1 8206003
31A 25” Long Flue Ba󰀪e 8 12 16 20 24 28 32 36 40 44 111910-01
31B 23” Long Flue Ba󰀪e 2 3 4 5 6 7 8 9 10 11 111910-02
31C 21” Long Flue Ba󰀪e 2 3 4 5 6 7 8 9 10 11 111910-03
REPAIR PARTS FOR BARE BOILER ASSEMBLY (Continued)
