Displaysymbolsexplanaon:
Auto Clean symbol appears in right
upper part of display. Acve auto
cleaning symbol means boiler automac
cleaning mode.
Crossed-out ame symbol appears
in upper right part of display.
Means that the boiler enters into
Exnguish mode.
CH priority /Radiator/ symbol
appears in upper part of display.
Means than Central Heang priority is
set to heat up the central heang.
Domesc Hot Water /shower/
priority symbol appears in upper
part of display. Means than DHWpriority
is set to heat up the domesc hot water.
When set DHW temperature is reached,
DHW pump stops and CH pump is
acvated.
Parallel pumps /shower and
radiator/ symbol appears in upper
part of display. Means that is set equal
priority to both pumps. They work in
parallel and are controlled by
temperature sensors.
Summermode /shower and sun/
symbol means than is set Summer
heang mode. Only DHW pump is acve.
Burner ame symbol appears in
upper right part of display. Means
that burner is acvated. Burner goes into
Ignion mode and upcoming boiler re
up.
Flame 3 symbol means Maximum
output mode of boiler. In this
mode the boiler operates at maximum
output.
Flame 2 symbol means Medium
outputmodeof boiler. In this mode the
boiler operates at paral output.
Flame 1 symbol means Lowoutput
mode of boiler. In this mode the
boiler operates at minimum output.
This symbol means Suspendmode
of boiler.
The noce "Hi" appearance on the
screen where the boiler
temperature is displayed means
that the measured Boiler body
temperature is above 120°C. Flashing
and beeping alarm is acvated. When
the issue is corrected, nocaon can be
deleted. When disconnect the boiler
from electrical supply for few seconds
and then switch on it again, boiler goes
back to normal operaon. Nofy the
authorized installer/ service to be
performed immediately inspecon of
theboilerandheanginstallaon.
Boiler increased temperature.
Those two symbols appearance on
the screen where the boiler
temperature is displayed means that
boiler temperature has increased up to
99°C.
Nofy the authorized installer/ service
tobeperformedimmediatelyinspecon
oftheboilerandheanginstallaon.
Errorsymbol appears in right upper
part of display. Flashing and beeping
error symbol mean error or fault in
boiler operaon. Use “Enter“ buon to
move to next screen with error
nocaon in lower le part of display.
When the issue is corrected, error
nocaon can be deleted. When
disconnect the boiler from electrical
supply for few seconds and then switch
on it again, boiler goes back to normal
