TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
operaon (error nocaon is deleted).
Nofy the authorized installer/ service
tobeperformedimmediatelyinspecon
oftheboilerandheanginstallaon.
Factoryseng-Alarms
BB
ALARM
Reverse re Alarm (when
the thermostat contact OD
input is open)
SENSOR
E1
Boiler Temperature Sensor is
missing (input B)
SENSOR
E2
Boiler Temperature Sensor
Short circuit ( input B)
IGNITION
FAIL
Failure ingnion
DHW E1
Water Heater Temperature
Sensor is missing (input WH)
DHW E2
Water Heater Temperature
Sensor Short circuit (input
WH)
CHbtm
E1
Temperature sensor of lower
part of buffer tank is missing
(when in chosen scheme
with buffer tank)
CHbtm
E2
Short circuit of temperature
sensor of lower part of
buffer tank (when in chosen
scheme with buffer tank)
CHtopE1
Temperature sensor of
upperr part of buffer tank
is missing (when in chosen
scheme with buffer tank)
CHtopE2
Short circuit of temperature
sensor of upper part of
buffer tank (when in chosen
scheme with buffer tank)
When restarng the controller alarm
is deacvated.
"С" symbol means that
the motor of automac
cleaning system is
acvated.
Symbol “T”
indicates, that room
termostat has been acvated.
In “CHonly” mode when there is a signal
from room termostat, the burner burns
5 min at max power, followed by transer
to power level 2. Aer 5 min the burner
transfers to power level 1, and aer 5
min transfers in Suspend mode. When
there is no signal from room termostat
or there is non-fulllled requirement for
DHW, the burner will re up.
In “CH + DHW” mode when DHW
(Domesc hot water) requirement is
fulllled and there is a signal from room
termostat, the burner burns 5 min at max
power, followed by transfer to power
level 2. Aer 5 min burner transfers to
power level 1 and aer 5 min transfers
to Suspend mode. Hen there is no
signal from room termostat or there is
non-fulllled requirement for DHW, the
burner will re up.
When room termostat is acvated, CH
pump stops in both modes (CH Only,
CH+DHW). In CH+DHW mode when
there is a signal from room termostat, CH
pump turns o. The burner counnues
to burn unl DHW(Domeschotwater)
requiremend is fulllled.
In "Summer Mode" room thermostat is
not acve.
Lightsforoperang:
- Pumpheangsystem.
- PumpDomeschotwater.
9.2.User`smenu
9.2.1.Inial(start-upscreen)"Standby"
For access to user sengs menu press
and hold funconal key F for 3-4 seconds.
