TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
TECHNICAL PASSPORT. INSTALLATION and OPERATION MANUAL
30
Pell 25 Pell 40 Pell 70 Pell 90 Pell 150
Actuator Parametervalue:
Service code 00000012
Cleaning Setup
Fan 180 sec
Cleaner 20 sec
Use Cleaner Cleaner
v On start
v On Stop
Ignition Setup
Retries 3
Feed 30 sec 35 sec 35 sec 35 sec 35 sec
Ignition Setup
Heater 3 min
Fan B/E
2 min
15/1
Burn Level
dt>8 dt>8 dt>8 dt>8 dt>8
dt>4 dt>4 dt>4 dt>4 dt>4
dt>0 dt>0 dt>0 dt>0 dt>0
Setup
Feed 6 sec 10 sec 10 sec 6,2 sec 10,2 sec
Cycle 20 sec 20 sec 20 sec 20 sec 20 sec
Fan B/E 32/1 29/1 26/1 35/1 50/1
Setup
Feed 50% 50% 50% 50% 50%
Fan B/E 20/1 20/1 20/1 22/1 32/1
Setup
Feed 30% 30% 30% 30% 30%
Fan B/E 25/1 17/1 17/1 15/1 17/1
Suspend
Feed 5% 5% 5% 5 % 5 %
Fan B/E 15/1 17/1 17/1 5/1 17/1
Suspend Time - 5 min
Interm. Cleaning
Cycle 30/0 30/0 30/0 30/0 30/0
Fan B/E 50/1 50/1 50/1 50/1 50/1
Auto Clean Setup
v 8:00 v 14:00 v 22:00
□ 00:00 □ 00:00 □ 00:00
Addons Activacion
v CH Pump
v DHW Pump
v Termostat
CH Mode
v Thermostat
Buffer
Hardware Setup
v Cleaning Motor
v Tstat NO
Vacuum Feeder
v NO
NC
Burner Feeder Duty 300%
Ir Level Setup
Ign > 100/020 s
Ext < 040/060 s
Set Temperature Max 85
o
C
Test Fan Speed 00
Test EFan Speed 00
Test Outputs
FF /Fuel Feeder – main auger/
BF /Burner Feeder – internal burner auger /
feeder/
CH /Central Heang pump 220V/
DHW /Domesc Hot Water pump 220V/
Ign /Ignion/
CM /Cleaning Motor/
