BUSCH DUPLEX - Check Oil Level; Oil and Oil Filter Change

8 | Maintenance
0870S03226_VRD 2072-3108_-0000_IM_en
23 /
44
8.2 Check oil level
Proceed as follows:
• Switch off the vacuum system.
• Wait 1 minute after switching off the vacuum pumps, before checking the oil level.
Top up with oil if necessary.
8.3 Oil and oil filter change
ATTENTION!
Operation of the vacuum pump without oil will cause severe damage to it quickly.
• Only use oils approved by Busch.
For information to the oil type and oil volume, see the technical data
(chap. 15) and oil (chap. 16).
Follow the figures
Fig. 11 : Drain oil
MAX
MAX
MAX
MIN
MIN
MIN
Drain pan
1 x o-ring, part no.:
see “Maintenance kit” (spare parts)
