8.4 Replacing the exhaust filters
Follow the figures
Fig. 14 : Remove the exhaust filter
Fig. 15 : Insert and tighten the new exhaust filter
10 mm wrench
1 x exhaust filter (EF)
Original spare parts from Busch
1 x exhaust filter (EF), part no.:
see “Maintenance kit” (spare
Check 2 x o-rings
10 mm wrench
Max. permissible torque: 4 Nm
