Water softener Type AQA smart AQA smart C
Nominal diameter of the connection DN 32 (G 1 1/4“ AG)
Nominal pressure (PN) bar 10
Operating pressure bar 2,5 - 8,0
Nominal flow in acc. with EN 14743 (DIN 19636) m
3
/h 1,4 (1,7)
Pressure loss at nominal flow bar 0,7
The values for capacity and consumption are the same for both systems
Control settings of the capacity tP 1 2 3
Recommended area of use Residential units 1-2 3 4
Nominal capacity in acc. with EN 14743 m
3
x °d (mol) 9 (1,6) 13 (2,4) 18 (3,2)
Quantity of regenerating agent (approx.) kg 0,35 0,5 0,8
Regeneration, water requirement* litre 27 39 50
Maximum flow** m
3
/h 1,4
Quantity of resin Liter 7
Supply of regenerating agent, max kg 15 50
Network connection V/Hz 230/50
Connected rating in operation / regeneration W 4,0
Energy consumption pro regeneration kWh 0,0013
Unit voltage V 18 ~
Protective class IP 53
Water temperature/Ambient temperature, min.-max. °C 5 - 30 / 5 - 40
Air humidity Non-condensing
Height H mm 630 1090
Width B mm 390 390
Depth, approx. T
1
mm 470 470
Depth, approx. T
2
mm 570 570
Connection height of overflow hose S mm 283 650
Connection height, approx. A mm 495 960
Connection width mm 60 60
Sewer connection, at least DN 50 50
Operating weight, approx. kg 40 100
Production number with Multiblock X 6-501087 6-501093
Production number without Multiblock X 6-501092
-
Item number with Multiblock X in Austria 6-501090
12 Technical data
* Depending on the primary pressure
** Maximal flow: Short-term flow with which the soft water system can be operated. With a maximum flow
and completely closed blending valve, the soft water hardness is less than 10% of the input water hardness.
