4.5.2 Fix the System
• The right side of the shell plate has 6 screws.
• The direction of rotation is as shown in the below diagram that shows the side shell
being removed.
• The left 3 (near the connection interface side) need to be completely removed.
• The 3 on the right side don’t need to be removed, just loosen them:
> Related tool: cross screwdriver (D6*150))
