Parameter MiniES-P30B3 - E-R2
On-grid parameter
Rated voltage AC230V/1Phase
Maximum current 13A
Rated frequency (range) 50HZ(48.5HZ-51.5HZ)
Maximum power 3KW
Current harmonic <5%
Off-grid parameter
Rated voltage AC230V/1Phase
Rated current 8A
Maximum current 16A (protection in 5s)
Rated power 2KVA
Rated frequency 50HZ
Rate of current harmonic distortion <3%
Off-grid protection
1~1.1 times rated power over load: protection in 15min
1.1~1.5 times rated power over load: protection in 15min
1.5~2 times rated power over load: protection in 15min
Battery parameter
Rated voltage (range) 52V (DC44.8V-DC57.6V)
Battery type LiFePO4
Basic battery capacity 3KWh
Other parameter
Size of product 680mm (W) x 256mm (D) x 610mm (H)
Net weight 96kg
Working humidity 5% ~ 95%
IP type IP32 (indoor)
Noise <2000m
Way of cooling Air cooling
Communication interface RS485*1/Ethernet (RJ45) *1/current transformer (CT)
Working temperature 0ºC~40ºC(32~104ºF)
Storage temperature 0ºC~40ºC(32~104ºF)
