iNetVu New Gen Troubleshooting Guide
C-COM Satellite Systems Inc.
Step 2: Testing the Wiring Harness.
a. Disconnect the switch from the internal wiring harness and place a paper clip or a looped wire
in the connector going to the wiring harness.
b. From the iNetVu Mobile 7000 Controls screen does the AZ ST come ON?
If YES, this concludes the Switch has failed
If NO, proceed to Step 3
Step 3: Testing the Sensor Cable.
a. Disconnect the sensor cable from the Platform and place the paper clip on the sensor cable
shorting out the pins corresponding to the Switch you wish to test.
b. From the iNetVu Mobile 7000 Controls screen does the AZ ST come ON?
If YES, this concludes the Wiring Harness has failed
If NO, proceed to Step 4
