KEY FEATURES
The CAST XFP 1 loop 16 zone analogue addressable fire alarm panel (Part No. XFP501E/CA) is
designed for use with fire and security systems and offers the following features:
• Certification by the LPCB to EN54 parts 2 and 4.
• Full compatibility with C-TEC’s CAST
®
(C-TEC Addressable System Technology) - a powerful,
proprietary communication p
rotocol.
• Short-circuit protected loop driver (rated at 500mA, 40V), capable of supporting up to 255
addressable CAST devices. Each CAST loop device is fitted with a short-circuit isolator.
• Two CAST device addressing options - automatically by the panel (AUTO ADDRESS & LOOP LEARN
functions), or manually using the CAST Handheld Programmer (Part No. CAPROG).
• Ability to change a device’s address.
• Ability to detect and fix duplicate addresses.
• Ability to detect swapped loop devices.
• Ability to turn all device polling LEDS on/off.
•
Fast response time from fire detection to multiple output groups.
• Two independently programmable conventional sounder circuits.
• Two programmable auxiliary inputs.
• A fault relay output and three programmable relay outputs with volt-free changeover contacts.
• A selection of zone dependency functions (EN54-2 Clause 7.12, type A, B or C) as detailed below:
Type A - If there is an alarm from a detector, the panel will look for a confirmatory alarm from
the same, or another, detector in the same zone before a full alarm is established. If there is no
confirmatory alarm, the first alarm will automatically reset.
Type B - As type A except the confirmatory signal must be from another detector in the same zone.
Type C - As type A except the confirmatory signal may also be from another zone and the first
alarm will not automatically reset.
• A day (building occupied) and night (building unoccupied) time function.
• An investigation delay period function (programmable for length of time, which zones it applies
to and whether or not it operates in day/night mode).
• Individual sensitivity settings for each device.
• EN54-2 Clause 7.8 re-sounding fire alarm devices.
• EN54-2 Clause 7.11 delays to outputs and a phased evacuation facility.
• EN54-2 Clause 7.13 alarm counter to record the number of alarm states (maximum of 999 counts).
• EN54-2 Clause 8.3 reporting of faults from heat detectors, optical detectors & multi-detectors.
• EN54-2 Clause 9.5 disablements of addressable points individually.
• An integral 1.5A EN54-4 switched mode PSU.
• Earth fault monitoring.
• Keypad code to enter levels 2 & 3. Keyswitch entry to access level 2.
• 40 characters of custom text per device.
• Comprehensive EN54-2 Clause 10 test, with maintenance and commissioning functions.
• Windows based PC programming tools (Part No. XFP507) that MUST be used to configure the system.
ENGINEERING MANUAL • Approved Document No. DFU5010000 Rev 4 • Page 4 of 48
CAST XFP 16 ZONE ANALOGUE ADDRESSABLE FIRE ALARM PANEL
Networking (Optional)
If required, the panel can be configured to sit on a non-redundant network of up to eight connected
CAST XFP main panels (any variant), OR you can have up to eight XFP repeaters connected to one non-
networked CAST XFP main panel. If you want to utilise either of these options, the panel will require a
separately available network driver card (Part No. XFP761). See page 12 for details.
Note: The CAST XFP network and XFP repeaters
have not been assessed to EN54-2.
