C-TEC CAST XFP User Manual

DISPLAY FIRE EVENTS
This function is only available if there are active fire conditions on the system.
Enter AL3 (4444) > Display Fire Events.
If available, press the Accept
4button and a window similar to the one below will appear:
Pressing the
5and6buttons will scroll the display through all active fire conditions. More detailed
information can be viewed by pressing the panel’s More Information button.
DISPLAY FAULT EVENTS
This function is only available if there are active faults on the system.
Enter AL3 (4444) > Display Fault Events.
If available, press the Accept
4 button and a window similar to the one below will appear:
Pressing the
5and6buttons will scroll the display through all active faults. More detailed information
can be viewed by pressing the panel’s More Information button.
DISPLAY DISABLEMENTS
This function is only available when there are active disablements on the system.
Enter AL3 (4444) > Display Disablements.
If available, press the Accept
4button and a window similar to the one below will appear:
Pressing the
5and6buttons will scroll the display through all active disablements.
DISPLAY ZONES IN TEST
This function is only available if one or more zones are being tested.
Enter AL3 (4444) > Display Zones in Test.
If available, press the Accept
4button and a window similar to the one below will appear:
Pressing the
5and6buttons will scroll the display through all zones currently in test.
ENGINEERING MANUAL • Approved Document No. DFU5010000 Rev 4 • Page 19 of 48
CAST XFP 16 ZONE ANALOGUE ADDRESSABLE FIRE ALARM PANEL
Last Zone: 1:North Stairs :Fire!
1 Zone
Zone 1: Ground Floor
There are faults on this zone
Zone 1: Shop floor
On: This Panel: Is Disabled
Zone 1: North Stairs
Is On Test
A detailed description of the functions available at access level 3 can be found below.
