SETUP PASSWORDS
This function allows you to change the access codes required to enter the panel’s access level 2 or 3
menu options.
Enter AL3 (4444) > Setup Passwords.
When selected, press the Accept
4button and the following window will appear:
Press the
5and6buttons to scroll to the desired option and press the Accept4button. The following
message will appear if the CHANGE ACCESS LEVEL 2 CODE prompt is selected:
Using the
5(1) 4(2) 6(3)3(4) buttons, enter the new four digit access level 2 code. After the fourth
digit has been entered, the panel will request you confirm the new code by re-entering it.
Enter the code again by pressing the
5(1) 4(2) 6(3)3(4) buttons in same sequence. If the two codes
match, the new code will be accepted. If you type an incorrect confirmation code, you will be prompted
to start the code entry sequence again. The same process can be used to change the access level 3 code.
BE SURE TO KEEP A RECORD OF ANY CHANGED CODES FOR FUTURE USE.
CHANGE ACCESS LEVEL 2 CODE?
Change Access Level 3 code
Enter NEW Access Level 2 code:
Enter NEW Access Level 2 code:****
Confirm New Access Level 2 code:
CONNECT TO PC
This function allows you to activate the panel’s PC connection for system programming purposes. The
panel’s cause and effects programming, device and zone naming, zone dependency functions, etc.,
MUST be done using panel’s PC programming tools (Part No. XFP507).
Enter AL3 (4444) > Connect to PC.
When the CONNECT TO PC prompt appears, press the Accept
4button. If all connections are correct,
the following message will appear:
PC connected...
Press ESC to disconnect from PC
CAST XFP 16 ZONE ANALOGUE ADDRESSABLE FIRE ALARM PANEL
ENGINEERING MANUAL • Approved Document No. DFU5010000 Rev 4 • Page 20 of 48
