5 Option
5.1 Cutter/Perforation Cutter
The cutter /perforation cutter contained in the contents of delivery must be
mounted to the printer during the initial start-up.
1
4
5
1
3
2
Fig. 13 Mount Cutter or Perforation Cutter
1. Put snap arm (5) of the cutter with the groove (4) rst into the guide on the
retainer (2).
2. Push cutter (1) down into the holders (3).
3. Fold up cutter (1) so that is snaps it at both sides of the retainer (2).
