14 14
4 Loading Material
4.3 Loading Labels for Peel-off Mode
Attention!
Place the printer so that the liner can run down without hindrance.
A label jam can cause malfunctions in printing operations.
2 21
Pressure roller in parking position Pressure roller in working position
Figure 13 Activation of the pressure roller
Move the pressure roller (2) of the control panel (1) from the parking into the working position.
In order to achieve this use on both ends of the roller and guide it into the working position.
Figure 14 Loading labels for peel-off mode
Load labels 4.1 on page 11 or 4.2 on page 13.
Removethelabelsfromtherst15cmofthematerial.
Feed the liner (3) out between the control panel (1) and the printer.
Lock the control panel into place and close the cover.
Initiate a synchronization 5.1 on page 18.
