7
2 Installation
2.2 Unpacking and Setting-up the Printer
Lift the label printer out of the box.
Check label printer for damage which may have occurred during transport.
Check delivery for completeness.
Contents of delivery:
• Label printer
• Power cable
• USB cable
• Operator's Manual
• DVD with label software, Windows driver and documentation
Note!
Please keep the original packaging in case the printer must be transported or returned.
Attention!
The device and printing materials will be damaged by moisture.
Only set up label printers in dry locations protected from water and moisture.
Set up printer on a level surface.
2.3 Connecting the Device
The standard available interfaces and connectors are shown in Figure 3.
2.3.1 Connecting to the Power Supply
The printer is equipped with a wide area power unit. The device can be operated with a supply voltage of
230 V~/50 Hz or 115 V~/60 Hz without adjustment.
1. Check that the device is switched off.
2. Plug the power cable into the power connection jack (21).
3. Plug the power cable into a grounded socket.
2.3.2 Connecting to a Computer or Computer Network
Attention!
Inadequate or no grounding can cause malfunctions during operations.
Ensure that all computers and cables connected to the label printer are grounded.
Connect the label printer to a computer or network with a suitable cable.
FordetailsonthecongurationoftheindividualinterfacesCongurationManual.
2.4 Switching on the Device
When all connections have been established:
Switch the printer on at the power switch (20).
The printer performs a system test, and then shows the system status Ready in the display (7).
