26 26
5 Block Diagram
Printer No. 1 Printer No. 2
SQUIX 4...P 5977331 SQUIX 4/300... 5977444
SQUIX 4...T 5952598 SQUIX 4/600... 5977380
SQUIX 4.3/200... 5977382
SQUIX 4.3/300... 5977383
Fig. 19 Block diagram

Other manuals for CAB SQUIX

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the CAB SQUIX and is the answer not in the manual?

CAB SQUIX Specifications

General IconGeneral
Print TechnologyThermal Transfer / Direct Thermal
Print Resolution300 dpi
Max Print Speed300 mm/s
DisplayLCD
InterfacesUSB, Ethernet, Serial (RS232), USB Host
Memory64 MB RAM
Media SensorsReflective, transmissive
Label Length5 to 4000 mm
KeyboardOptional
Supported MaterialsPaper, plastic, textile
