CAL Controls 3300 - Cycle Time Configuration; Automatic Acceptance of Autotune Cycle Time; Manual Cycle Time Selection Before Autotune

If this cycle-time is suitable press and hold both ▲ and ▼
buttons for 3 seconds to enter it into the controllers
memory.
If the calculated cycle-time is not compatible with the
switching device press and hold the ✱ button then press
and hold ▲ or ▼ until a more suitable cycle-time is
displayed. Release the buttons, then press and hold both
▲ and ▼ buttons for 3 seconds to enter it into the
controllers memory.
Pre-Select Automatic Acceptance of Any Autotune
Cycle-time
Before selecting Autotune, enter program mode.
Select CYC.T
Press and hold the ✱ button then press and hold ▼ until
indexing stops and
A- - is displayed.
Note:
A- - indicates that no cycle-time exists.
Press and hold ▼ to scroll to TUNE
The controller will now alternately display TUNE and
oFF . Press and hold the ✱ button and use ▲ to select
either
on or At.SP . Release ▲.
The controller will now run Autotune and will accept the
calculated cycle-time.
To Pre-Select Cycle-time Before Autotune
Before selecting Autotune, enter program mode.
Select CYC.T
Press and hold the ✱ button, then press ▲ to increase
or ▼ to decrease the displayed cycle-time. Release
buttons when required value is displayed.
Select TUNE or index to another function then exit
program mode.
Proportional cycle-time
10
81
ON.OF
0.1
20
A --
Factory setting
ON/OFF
Autotune calculated
cycle-time
Manual settings
Seconds
✱ ▼
✱ ▲
Proportional Cycle-time (continued)
