User's Guide — 43
Numeric Thread Size
scroll
characteristics:
Note: The default U.S. Thread Class is 2B (Internal). To view the
current Thread Class, press gt. To change the class, press
t again.
Thread Size calculations for Pitch, Major, and Minor Diameter
attributes are compliant with ANSI/ASME B.1.1-2003 and ANSI/
ASME B.1.13M-2005.
g*
ALL CLEARED 0.
1. Verify Thread Class is set to 2B:
gt (Thread Class)
U.S. INT. THREAD
2B 2.
2. Enter the Thread Size:
8t
THREAD SIZE
2B 8 -
3. Enter the TPI:
32t
THREAD SIZE
2B 8 - 32
4. Find the available Internal Thread characteristics:
t
THREAD PITCH
0.031 INCH
t
TAP DRILL SIZE
#29 0.136 INCH
t
ROLL TAP DRILL
3.750 MM
(cont'd)
