User's Guide — 51
(cont'd)
3. Find the Ideal, Maximum and Minimum Wire Sizes:
gS (Wire Size)
IDEAL WIRE SIZE
0.036 INCH
S
MAX WIRE SIZE
0.056 INCH
S
MIN WIRE SIZE
0.035 INCH
3-Wire Measurement – Known Thread Size and Wire Size
Note: When solving for 3-Wire Measurements and Pitch Diameters,
the calculator assumes the equivalent External Thread Type if an
Internal Thread Type is set (i.e., Internal 2B is assumed External
2A for U.S. Threads; Internal 6H is assumed External 6h for Metric
Threads).
Measurements
screw using 0.040 Inch wire:
OO 0.
1. Set the Thread Class to 2A:
2gt* (Thread Class)
U.S. EXT. THREAD
2A 2.
* If necessary, continue pressing t until the desired External
Thread Class is displayed.
2. Enter the Thread Size:
.375it
THREAD SIZE
2A 0.375 - INCH
3. Enter the Threads per Inch:
To Next Page
