User's Guide — 55
3. Enter the Start Angle:
20n
ANGLE
(Ө) 20.°
4. Enter Bolt Circle Diameter:
3.5d
DIAMETER
3.5 INCH
5. Enter the Number of Bolts:
3gd (Bolt Pattern)
NUMBER OF BOLTS
3.
6. Calculate center-to-center Spacing and the x and y
coordinates:
d
OC SPACING
3.031 INCH
d
BOLT POSITION
X-Ø1 11.644 INCH
d
BOLT POSITION
Y-Ø1 15.599 INCH
d
BOLT POSITION
X-Ø2 8.659 INCH
d
BOLT POSITION
Y-Ø2 16.125 INCH
d
BOLT POSITION
X-Ø3 9.696 INCH
d
BOLT POSITION
Y-Ø3 13.277 INCH
d
BOLT CIRCLE DIA
X-Ø2 3.500 INCH
d
BOLT PATTERN CTR
X-ØØ 10.000 INCH
(cont'd)
