CalderaSpas Elation - OLYMPIA

12
Electrical
Cutout
Air Vent Air Vent
Electrical
Cutout
BOTTOM
VIEW
Pedestal
Overalll
80”
84”
Pedestal
80"
Overall
84"
DOOR SIDE
4.0” (11cm)
ELECTRICAL
CUTOUT
5.5” (14cm)
1.5” (4cm)
36”(92cm)
33” (84cm)
SPA DRAIN
DOOR
21.75”
5.5”
ELECTRICAL
CUTOUT
AIR VENTS
DO NOT BLOCK
DOOR
29.875”
DOOR
20.625”
LOCATED
BEHIND DOOR
FRONT
VIEW
(14cm)
(52cm)
(75cm)
(75cm)
(213cm)
(203cm)
(203cm)
(213cm)
4.0” (11cm)
NOTE: Watkins Manufacturing Corporation requires that the Moorea be installed on a minimum 10.2 cm thick reinforced concrete pad or structurally sound deck able to
support the “dead weight” found in the spa specification chart.
WARNING: The Olympia must not be shimmed in any manner.
OLYMPIA
NOTE: All dimensions are approximate; measure your spa before making critical design or pathway decisions.
DIMENSIONS
