59
1002595 ISSUE 5 M172 VARIHEAT
Fresh air
module
Air filter access panel
Variheat wi fresh air module,
negative pressure module
and/or resistance heater module
Resistance heater module
(if reqd)
in is position only
Service panel
Electric box assembly
Service panel
Supply air to pool hall
Service panel
Service panel
Service panel
Variheat wiout optional modules
Service panel
Service panel
Air filter access panel
Alternative supply air position
Service panel
Cable entry points
Supply air to pool hall
Electric box assembly
Cable entry points
600/900 horizontal versions viewed from opposite side
