Calorex Variheat AA600 - Page 63

63
1002595 ISSUE 5 M172 VARIHEAT
1200/1500 horizontal versions
Variheat wiout optional modules
289
60
800
Service panel
1479
113
Electric box assembly
Return air from pool hall
160
66256
772
Air filter access panel
50
333
Supply air to
pool hall
692
800
Fresh air
module
Service
panel
Damper
145
770
2328 355
1558
100
140
Alternative
400
160
60
182 140 260
Air filter access panel
Variheat wi fresh air module,
negative prseeure module
and/or resistance heater module
Resistance heater module (if fitted) in is position only
Service panel
190
Spigot
Alternative
2249
Service panel
Supply air to pool hall
289
Fresh air module spigot detail
(view from air on)
(2 spigots)
diameter 225mm
302
187
Spigot Spigot
Damper
Negative pressure module
(1 spigot)
diameter 157mm
203
supply air positions
LPHW in 1" BSPM
LPHW out 1" BSPM
Drain ¾" BSPM
LPHW in 1" BSPM
LPHW out 1" BSPM
Drain ¾" BSPM
supply air positions
Electric box assembly
Service panel
Service panel
Touchscreen User Interface
Touchscreen User Interface
Supply air to pool hall
Exhaust
air out
Fresh
air in
