Calorex Variheat AA600 - Page 64

64
1002595 ISSUE 5 M172 VARIHEAT
VARIHEAT AA SYSTEM OWNER INSTALLATION MANUAL
Variheat wiout optional modules
Service panel
Electric box assembly
Service panel
Air filter access panel
Service panel
Fresh air
module
Service
panel
Air filter access panel
Service panel
Variheat wi fresh air module,
negative pressure module
and/or resistance heater module
Resistance heater module (if fitted) in is position only
Service panel
Alternative
supply air position
Service panel
Supply air to pool hall
Cable entry points
Cable entry points
Supply air to pool hall
1200/1500 horizontal versions viewed from opposite side
