Chapter 3: System planning Site planning
Page
3-14
Table 81 PMP/PTP 450 Series wind loading (lb force)
Type of ODU Max surface area
(square feet)
Wind speed (miles per hour)
100 105 110 115 120
External 60º sector
antenna – 2.4 GHz
AP
2.9 122 134 147 161 175
External 60º sector
antenna – 5 GHz AP
0.71 29.8 33 37 39 43
External 90º sector
antenna – 5 GHz AP
0.89 37 41 45 49 54
SM 0.29 12 13 15 16 18
Integrated High
Gain, Ruggedized
1 42 46 51 56 60
Integrated Dish 1.49 63 69 76 83 90
Table 82 PMP 450b Series wind loading (Newton)
Type of ODU
Max surface area
(square meters)
Wind speed (miles per hour)
160 170 180 190 200
Integrated Mid-Gain 0.03 80 90 101 113 125
Integrated High Gain 0.13 347 392 440 490 543
Table 83 PMP 450b Series wind loading (lb force)
Type of ODU
Max surface area
(square feet)
Wind speed (miles per hour)
100 105 110 115 120
Integrated Mid-Gain 0.33 13 15 16 18 19
Integrated High Gain 1.41 59 65 71 78 85
