Cambium Networks PMP 450 AP Planning And Installation Guide

Chapter 2: System hardware ODU interfaces
Page
2-36
PMP/PTP 450b High Gain SM
The Ethernet and AUX ports are on the rear of the integrated and connectorized ODUs (Figure 25).
These interfaces are described in Table 40.
Figure 26 PMP/PTP 450b High Gain SM - ODU rear interfaces
Table 41 PMP/PTP 450b High Gain SM – ODU rear interfaces
Port name
Connector
Interface
Description
PSU/Ethernet
Port
RJ45 PoE input Power over Ethernet (PoE).
10/100/1000BASE-T
Ethernet
Data
Audio AUX
Port
Standard
3.5 mm
headphones
Alignment tone input 3.5 mm audio jack for alignment tone
