Chapter 2: System hardware System Components
Page
2-22
• Power Supply, 60 W, 56 V with 1000BASE-T or GigE
• AC+DC Enhanced Power Injector
• Power over Ethernet midspan, 60 W, -48 VDC Input
• CMM4 with external 56 V power supply and CMM4 to 450i Series ODU cable (Dongle)
• IEEE802.3at power injector
Note
The 900 MHz SM is based off of the 450 Series , please see Power supply – PMP/PTP
450 Series on page 2-28.
Warning
Always use an appropriately rated and approved AC supply cord-set in accordance
with the regulations of the country of use.
Warning
The PMP 450 Ruggedized High Gain Integrated Subscriber Module (Cambium part
numbers C035045C014A and C036045C014A), while encapsulated in a 450i-type
enclosure, contains 450 circuitry which must be powered via 30 VDC. Powering
these SMs with a 56 VDC will damage the device.
Please refer to Cabling on Page 2-37 for details on maximum cable lengths between power injector and
PMP/PTP 450i.
PSU part numbers
Table 27 PSU part numbers for PMP/PTP 450i Series
Power supply, 60 W, 56 V with Gbps support N000065L001B
AC+DC Enhanced Power Injector C000065L002C
Line Cord, Fig 8 – US N000065L003A
Line Cord, Fig 8 – UK N000065L004A
Line Cord, Fig 8 – EU N000065L005A
Power over Ethernet midspan, 60 W, -48 VDC Input N000000L036A
Power supply, 30 W, 56 V – Gbps support N000000L034A
