Chapter 4: Preparing for installation Testing system components
Page 4-11
Main port pinout
Table 95 Main port pinout
RJ45 pin
Description
1 +TxRx0
2 –TxRx0
3 +TxRx1
4 +TxRx2
5 –TxRx2
6 –TxRx1
7 +TxRx3
8 –TxRx3
Aux port pinout
Table 96 Aux port pinout
RJ45 pin
Description
1 +TxRx0
2 –TxRx0
3 +TxRx1
4 GPS power out, Alignment tone out, GPS data out
5 GPS data in
6 –TxRx1
7 GPS 0v
8 GPS Sync in
