Cambium Networks PMP 450 AP Planning And Installation Guide

Chapter 2: System hardware Cabling
Page
2-39
SFP module kits
SFP module kits allow connection of a PMP 450 Series ODU to a network over an Optical Gigabit
Ethernet interface (1000BASE-LX or 1000BASE-SX) full-duplex mode.
Order SFP module kits from Cambium Networks (Table 44).
Table 44 SFP module kit part numbers
Cambium description
Cambium part number
Single Mode Optical SFP Interface per ODU C000065L008A
Multi-mode Optical SFP Interface per ODU C000065L009A
2.5GBASE-T Copper SFP Interface per ODU C000065L011A
To compare the capabilities of the two optical SFP modules, refer to Table 45 and Table 46.
Table 45 Single Mode Optical SFP Interface per ODU (part number C000065L008)
Core/
cladding
(microns)
Mode
Bandwidth at
1310 nm (MHz/km)
Maximum
length of optical
interface
Insertion loss
(dB)
62.5/125 Multi 500 550 m (1800 ft) 1.67
50/125 Multi 400 550 m (1800 ft) 0.07
50/125 Multi 500 550 m (1800 ft) 1.19
10/125 Single N/A 5000 m (16400 ft) 0.16
Table 46 Multi-mode Optical SFP Interface per ODU (part number C000065L009)
Core/
cladding
(microns)
Mode
Bandwidth at
850 nm (MHz/km)
Maximum
length of optical
interface
Insertion loss
(dB)
62.5/125 Multi 160 220 m (720 ft) 2.38
62.5/125 Multi 200 275 m (900 ft) 2.6
50/125 Multi 400 500 m (1640 ft) 3.37
50/125 Multi 500 550 m (1800 ft) 3.56
The upgrade kits contain the following components:
• Optical SFP transceiver module (Figure 28)
• Long EMC strain relief cable gland (Figure 29)
Note
PMP 450m supports Fiber SFPs from system release 15.0.3.
