Cambridge Audio Edge NQ User Manual

10
Remote Control
Last updated: September 2, 2022 12:51. Revision #5805
1. Standby/On
Switches the EDGE NQ between On and Standby mode.
2. Volume
Volume level adjustment.
3. Skip
Skips between previous and next tracks.
4. Play/Pause and Mute/Unmute
Play or Pause current track.
Press to mute or unmute the loudspeakers, pre-out, sub, and the headphone outputs.
Note: This remote function is source dependent. Where possible the source will be paused and for other sources the
output will be muted.
5. Source Selection
Used to navigate between the various sources on the player.
6. Programable Buttons
Press and hold to store the current source and its volume level.
Note: If the remote control will not function, please check that the batteries have not expired, and that there is nothing
blocking the front panel IR receiver.

Cambridge Audio Edge NQ Specifications

General

Type	Network Player / Preamplifier
DAC	ESS Sabre ES9018K2M
Maximum Resolution Supported	32-bit/384kHz PCM, DSD256
Ethernet	Yes
Weight	10.2 kg (22.5 lbs)
Inputs	2x Coax S/PDIF, 2x TOSLINK Optical, 1x USB Audio, 1x XLR
Outputs	1x RCA, 1x XLR, 1x Coaxial S/PDIF, 1x TOSLINK Optical
Streaming Services	Chromecast, Spotify Connect, TIDAL, Qobuz, AirPlay, Internet Radio
File Formats Supported	FLAC, ALAC, WAV, AIFF, MP3, AAC, WMA, OGG, DSD
Wi-Fi	Yes (802.11 b/g/n/ac)
Bluetooth	Yes, aptX HD
USB Audio Input	Yes
Headphone Output	Yes, 6.3mm jack
Dimensions	120 x 460 x 405mm (4.7" x 18.1" x 15.9")
