USB Audio
Last updated: September 2, 2022 12:51. Revision #5814
The USB Audio Input on your player is designed for use with PC and Mac computers. When connected, you will be able to playback music to the network
player directly from the computer’s apps, software or media players.
PC Setup
1. Connect your EDGE NQ to your PC.
Using a USB audio cable (Type A to Type B), connect the USB Audio In on your EDGE NQ to a USB port on the PC.
2. Select the USB Audio source.
If using the front panel source selector of your EDGE NQ, switch to USB Audio.
If using the StreamMagic app, go to the Home tab, then select USB Audio within the Sources section.
3. Navigate to the CA Control Panel which should now be installed in your Windows taskbar. This will show any connected Cambridge Audio USB Audio
device and current sample rate.
4. On your PC, navigate to Settings > System > Sound. Select the Edge NQ as your output device from the drop-down menu. This will appear as 'CA
Edge Range’.

Cambridge Audio Edge NQ Specifications

General

Type	Network Player / Preamplifier
DAC	ESS Sabre ES9018K2M
Maximum Resolution Supported	32-bit/384kHz PCM, DSD256
Ethernet	Yes
Weight	10.2 kg (22.5 lbs)
Inputs	2x Coax S/PDIF, 2x TOSLINK Optical, 1x USB Audio, 1x XLR
Outputs	1x RCA, 1x XLR, 1x Coaxial S/PDIF, 1x TOSLINK Optical
Streaming Services	Chromecast, Spotify Connect, TIDAL, Qobuz, AirPlay, Internet Radio
File Formats Supported	FLAC, ALAC, WAV, AIFF, MP3, AAC, WMA, OGG, DSD
Wi-Fi	Yes (802.11 b/g/n/ac)
Bluetooth	Yes, aptX HD
USB Audio Input	Yes
Headphone Output	Yes, 6.3mm jack
Dimensions	120 x 460 x 405mm (4.7" x 18.1" x 15.9")
