Cambridge Audio Edge NQ User Manual

24
8. Your PC’s output will now playback via the Edge NQ.
Mac Setup
1. Connect your EDGE NQ to your Mac.
Using a USB audio cable (Type A to Type B), connect the USB Audio In on your EDGE NQ to a USB port on the Mac.
Note: If using a Mac without a USB Type A port, you may also use USB Type C (Thunderbolt 3) to USB Type B connection.
2. Select the USB Audio source.
If using the front panel source selector of your EDGE NQ, switch to USB Audio.
If using the StreamMagic app, go to the Home tab, then select USB Audio within the Sources section.
3. Within the System Preferences of the Mac, locate the Sound settings. Select the CA Edge 2.0 as the output sound device.

Cambridge Audio Edge NQ Specifications

General

Type	Network Player / Preamplifier
DAC	ESS Sabre ES9018K2M
Maximum Resolution Supported	32-bit/384kHz PCM, DSD256
Ethernet	Yes
Weight	10.2 kg (22.5 lbs)
Inputs	2x Coax S/PDIF, 2x TOSLINK Optical, 1x USB Audio, 1x XLR
Outputs	1x RCA, 1x XLR, 1x Coaxial S/PDIF, 1x TOSLINK Optical
Streaming Services	Chromecast, Spotify Connect, TIDAL, Qobuz, AirPlay, Internet Radio
File Formats Supported	FLAC, ALAC, WAV, AIFF, MP3, AAC, WMA, OGG, DSD
Wi-Fi	Yes (802.11 b/g/n/ac)
Bluetooth	Yes, aptX HD
USB Audio Input	Yes
Headphone Output	Yes, 6.3mm jack
Dimensions	120 x 460 x 405mm (4.7" x 18.1" x 15.9")
