Pag.
- Manual code:
119DV74 ver.
01/2011
© CAME cancelli automatici s.p.a. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
Motor power supply: 230V A.C. 50/60Hz
Max draw.: 1,2A
Power: 150W
Opening time (90°):
A3000A = 19 s
A5000A = 32 s
Gear ratio: 1/36
Thrust: 400 ÷ 3000N
Duty cycle: 50%
Condenser: 10μF
Protection rating: IP44
Weight:
A3000A = 10 kg
A5000A = 11 kg
4.1 Gearmotor
This product is engineered and built by CAME cancelli automatici S.p.A. in compliance with applicable safety standards.
The electro-lock fitted irreversible gearmotor, is made up of two cast-aluminium half shells containing a gearmotor with epicycloid
gearbox system.
A double, electromechanical limit-switch system is fitted above the gate-movement worm-screw
4 Description
2.1 Intended use
1 Legend of symbols
This symbol tells you what to say to the end-users.
This symbol tells you to read the section with particular care.
This symbol tells you that the sections concern safety issues.
2 Intended use and restrictions
The ATI 230V gearmotor is designed to power residential and condominium swing gates.
Any use, other than that described above or installations performed in ways other than those described herein, are forbidden.
3 Reference Standards
“IMPORTANT INSTALLATION, SAFETY INSTRUCTIONS”
“CAUTION: IMPROPER INSTALLATION MAY CAUSE SERIOUS DAMAGE, FOLLOW ALL INSTALLATION INSTRUCTIONS CAREFULLY”
“THIS MANUAL IS ONLY FOR PROFESSIONAL OR QUALIFIED INSTALLERS”
2.2 Restrictions
4.2 Technical features
For its quality processes management Came Cancelli Automatici is ISO 9001 certified, and for its environmental management it
is ISO 14001 certified.
This product complies with the following standards: see declaration of conformity.
Gate leaf width
m
Gate leaf weight
kg
A3000A A5000A
2.00 800 1000
2.50 600 800
3.00 400 600
4.00 / 500
5.00 / 400
