CAME BKS08AGS User Manual

Page 19 - Manual FA01295-EN - 03/2023 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Power supply output for accessories
10 11 TS 1
24V 0
The output normally delivers 24 V AC.
The sum of the power draw for the connected accessories must not exceed 20 W.
Torque limiter
L1T L2T CT VS VF
24V 0
0
17
24
FR
1
2
3
4
SP
0
1
2
3
4
5 8
7
6
1
Grey cable
2
Brown cable
3
Red cable
4
Black cable
5
White cable
6
To vary the motor torque, move the corresponding Faston terminal to
one of the four positions; from 1 (minimum) to 4 (maximum).
7
Blue cable
8
Orange cable
Signalling devices
1
Flashing beacon
It flashes when the operator opens and closes.
2
Additional light
It increases the light in the manoeuvring area.
See function [F18].
3
Passage-open warning light
It notifies the user of the operator status.
See function [F10].
2
1
3
LNUVWE1EXW 24V O 10 11 TS 1 2 3 3P 4 5 7 CX CYL1T L 2T CT VS VF
L
N
U
V
W
24
V
O
L
1
T
L
2
T
CT
V
S
VF
