Safety devices
During programming, configure the type of action that must be performed by the device connected to the input.
Connect the safety devices to the CX and/or CY inputs.
If used, the CX and/or CY contacts must be activated during programming.
See function [F2] and/or [F3].
DELTA photocells
Standard connection
DELTA photocells
Connection with safety test
See function [F5] Safety devices test.
24V O 10 11 TS 1 2 3 3P 4 5 7 CX CY24
V
O
+
10
-
11 NO C NC
+
10
-
11
RX TX
24V O 10 11 TS 1 2 3 3P 4 5 7 CX CY
2
4
V
O
+
10
-
11 NO C NC
+
10
-
11
RX TX
DIR / DELTA-S photocells
Standard connection
DIR / DELTA-S photocells
Connection with safety test
See function [F5] Safety devices test.
24V O 10 11 TS 1 2 3 3P 4 5 7 CX CY24
V
O
+
10
-
2TXCNC TX 2
RX TX
24V O 10 11 TS 1 2 3 3P 4 5 7 CX CY24V
O
+
10
-
2TXCNC TX 2
RX TX
