Page 9 - Manual FA01295-EN - 03/2023 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Technical data
MODELS BKS08AGS BKS12AGS BKS18AGS BKS22AGS BKS18RGS
Power supply (V - 50/60 Hz) 230 AC 230 AC 230 AC 230 AC 120 AC
Motor power supply (V) 230 AC 230 AC 230 AC 230 AC 120 AC
Standby consumption (W) 4,5 4,5 4,5 4,5 4,5
Power (W) 520 380 480 580 580
Capacitor (μF) 25 25 31,5 35 60
Current draw (A) 4,5 3,3 4,2 5,1 4,2
Colour RAL 7024 RAL 7024 RAL 7024 RAL 7024 RAL 7024
Operating temperature (°C) -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55
Thrust (N) 800 850 1150 1500 1100
Maximum operating speed (m/min) 10,5 10,5 10,5 10,5 10,5
Pinion module 4 4 4 6 4
Reduction ratio 31 31 31 31 31
Protection rating (IP) 44 44 44 44 44
Insulation class I I I I I
Weight (kg) 21 18 19,5 21 19,5
Storage temperature (°C)* -20 ÷ +70 -20 ÷ +70 -20 ÷ +70 -20 ÷ +70 -
Average life (cycles)** 250000 250000 250000 250000 -
MODELS BKS08ALS BKS12ALS BKS18ALS BKS22ALS
Power supply (V - 50/60 Hz) 230 AC 230 AC 230 AC 230 AC
Motor power supply (V) 230 AC 230 AC 230 AC 230 AC
Standby consumption (W) 4,5 4,5 4,5 4,5
Power (W) 520 380 480 580
Capacitor (μF) 25 25 31,5 35
Current draw (A) 4,5 3,3 4,2 5,1
Colour RAL 7040 RAL 7040 RAL 7040 RAL 7040
Operating temperature (°C) -20 ÷ +55 -20 ÷ +55 -20 ÷ +55 -20 ÷ +55
Thrust (N) 800 850 1150 1500
Maximum operating speed (m/min) 10,5 10,5 10,5 10,5
Pinion module 4 4 4 6
Reduction ratio 31 31 31 31
Protection rating (IP) 44 44 44 44
Insulation class I I I I
Weight (kg) 21 18 19,5 21
Storage temperature (°C)* -20 ÷ +70 -20 ÷ +70 -20 ÷ +70 -20 ÷ +70
Average life (cycles)** 250000 250000 250000 250000
(*) Before installing the product, keep it at room temperature where it has previously been stored or transported at a very high or very low temperature.
(**) The average product life is a purely indicative estimate. It applies to compliant usage, installation and maintenance conditions. It is also influenced by other
factors, such as climatic and environmental conditions.
Fuse table
MODELS BKS08AGS BKS12AGS BKS18AGS BKS22AGS BKS18RGS
Line fuse 8 A-F 8 A-F 8 A-F 8 A-F 15 A-F
Control-board fuse 630 mA-F 630 mA-F 630 mA-F 630 mA-F 630 mA-F
Accessory fuse 1 A-F 1 A-F 1 A-F 1 A-F 1 A-F
MODELS BKS08ALS BKS12ALS BKS18ALS BKS22ALS
Line fuse 8 A-F 8 A-F 8 A-F 8 A-F
Control-board fuse 630 mA-F 630 mA-F 630 mA-F 630 mA-F
Accessory fuse 1 A-F 1 A-F 1 A-F 1 A-F
