L
1
A
B
C
D
Page 8 - Manual FB01002-EN - ver. 1 - 11/2017 - © CAME S.p.A. - The contents of this manual are subject to change at any time without prior notice.
Install the unit in a suitable position to
correctly detect the temperature, possibly
in an internal wall, avoiding installation
in niches, behind doors, curtains or near
heat sources.
Pull out the tab L and then pull the unit body
out from the frame as far as it will go B.
Press on the side flaps next to the symbol
to completely remove the unit body
from the frame C.
Insert 3 x alkaline LR03 AAA 1.5 V batteries
in position, respecting the polarity shown
on the bottom of the casing D.
