⑱ ⑲ ⑳ ㉑ ㉓ ㉔㉒
Page 12 - Manual FB01002-EN - ver. 1 - 11/2017 - © CAME S.p.A. - The contents of this manual are subject to change at any time without prior notice.
CAUTION!
The first time any button is pressed, this ONLY lights up the display, which remains on
for 15 seconds after the last time a button is pressed.
The device should only be cleaned using a soft cloth dampened with water.
⑱
Reset button.
⑲
Setting the clock and power-on or power-o delay time.
⑳
Programming the three temperature bands T1, T2, T3.
Setting operating parameters.
㉑
Selecting the device operating mode.
COOLING - HEATING - OFF
㉒
Buttons for selecting the desired time on the daily programming graph.
㉓
Button for selecting the day - see ⑰.
㉔
Button for copying the daily programming.
Function of internal buttons
To access the internal command buttons, pull out the tab ⑬ and then the unit body
from the frame.
