21 - Manual FA01413-EN - 02/2020 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
CY input
Associate a function with the CY input.
F3 CY input OFF (Default)
C1 = Reopen while closing (photocells)
C2 = Reclose while opening (photocells)
C3 = Partial stop Only with [Automatic close] activated.
C4 = Obstacle standby (photocells)
C7 = Reopening during closure (sensitive edges)
C8 = Reclose while opening (sensitive edges)
R7 = Reopen while closing (sensitive edges with 8K2 resistor)
R8 = Reclose while opening (sensitive edges with 8K2 resistor)
Safety devices test
Check that the photocells connected to the inputs are operating correctly, after each opening and closing command.
F5 Safety devices test OFF (Default)
1 = CX
2 = CY
4 = CX+CY
Hold-to-run
With the function active, the operator stops moving (opening or closing) when the control device is released.
When the function is active, it excludes all other control devices.
F6 Hold-to-run OFF (Default)
ON
Command 2-7
Associate a command with the device connected to 2-7.
F7 Command 2-7 0 = Step-by-step (default)
1 = Sequential
2 = Open
3 = Close
Command 2-3P
Associate a command to the connected device on 2-3P.
F8 Command 2-3P 0 = Partial opening (Default)
1 = Open
Obstacle with motor stopped
With the function active, the gate remains idle if the safety devices detect an obstacle. The function is active when the gate is closed, open or after a complete stop.
F9 Obst. with motor stopped OFF (Default)
ON
Additional light
Choose the operating mode of the lighting device connected to the output.
F18 Additional light OFF =Flashing beacon (Default)
1 = Cycle light.
The light remains off if an automatic closing time is not set.
2 = Courtesy light.
