CAME BX604AGS User Manual

7 - Manual FA01413-EN - 02/2020 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Usage limitations
MODELS BX604AGS BX608AGS BX608ALS
Pinion module 4 4 4
Maximum gate-leaf length (m) 14 14 14
Maximum gate-leaf weight (kg) 400 800 800
Technical data
MODELS BX604AGS BX608AGS BX608ALS
Power supply (V - 50/60 Hz) 230 AC 230 AC 230 AC
Motor power supply (V) 230 AC 230 AC 230 AC
Standby consumption (W) 5 5 5
Standby consumption with the RGP1 (W) module 0,8 0,8 0,8
Power (W) 560 520 520
Capacitor (μF) 20 20 20
Current draw (mA) 2,7 2,5 2,5
Colour RAL 7024 RAL 7024 RAL 7040
Operating temperature (°C) -20 ÷ +55 -20 ÷ +55 -20 ÷ +55
Thrust (N) 600 800 800
Maximum operating speed (m/min) 10,5 10,5 10,5
Cycles/hour 17 17 17
Consecutive cycles 6 6 6
Duty cycle 30 30 30
Motor thermal protection (°C) 150 150 150
Sound pressure level (dB A) ≤70 ≤70 ≤70
Protection rating (IP) 44 44 44
Insulation class I I I
Weight (kg) 15 15 15
Fuse table
MODELS BX604AGS BX608AGS BX608ALS
Line fuse 5 A-F 5 A-F 5 A-F
Control-board fuse 630 mA-F 630 mA-F 630 mA-F
Accessories fuse 1 A-F 1 A-F 1 A-F

CAME BX604AGS Specifications

General

Brand	CAME
Model	BX604AGS
Category	Gate Opener
Language	English
