5.10.2 Electrical connections to the on-board control panel with two-leaf gates
LEFT gate leaf
RIGHT gate leaf
Once fi nished with mounting, electrical connections and
adjustments, replace the cover and secure it using the hex
nut M4. Insert the release handle into the ‘LOCK’ position and
secure it.
