4 01/2015
© CAME S.p.A. - The data and information in this manual may be changed at any time and CAME S.p.A. is under no obligation to inform users of said changes
Connect the RG58 antenna cable to
the corresponding terminals.
6.7 Activating the radio command
Only for the AF43S / AF43SM radio-frequency cards:
position jumper as shown depending on the series of transmitters you are using.
Plug the radio-frequency card into the control board AFTER CUTTING OFF THE MAINS POWER SUPPLY (and disconnecting the batteries,
if any).
N.B.: The control board only recognises the radio-frequency card when it is powered.
AF card
