4 01/2015
© CAME S.p.A. - The data and information in this manual may be changed at any time and CAME S.p.A. is under no obligation to inform users of said changes
4.1 Operator
4 Description
2.1 Intended use
1 Legend of symbols
This symbol highlights parts which must be read with care.
This symbol highlights the parts which describe safety issues.
This symbol tells you what to tell the end-user.
2 Intended use and limits to use
The F7000 operator is designed and built by CAME S.p.A. in compliance with current safety regulations, to automate
residential property and apartment building swing-gates.
Any installation and use other than that specified in this manual
is forbidden.
3 Reference standards
2.2 Limitations to use
Operator with control board and articulated transmission arm for gate leaves of up to 2.3 m.
4.2 Technical data
CAME S.p.A. adopts the ISO 9001 certified quality-management and the ISO 14001 environmental-management systems. Came
only designs and manufactures in Italy.
This product is compliant with: see declaration of conformity.
Gate-leaf length 1 m 1.5 m 2 m 2.3 m max
Gate-leaf weight 300 kg max 250 kg 215 kg 200 kg
Opening 110 max
Power supply
230 V AC
Maximum power rating 160 W
Power draw when idle
A 1.4
Maximum Torque. 180 Nm
Opening time (90°)
18 S
Duty cycle 30%
Weight 11.6 kg
Condenser 10 µF
Protection rating IP54
Working temperature - 20 / +55°C
We suggest you always fit an electrolock onto swing gates for a more reliable closure.
