Make sure you have all the tools and materials you will need for the installation at hand to work in total safety and compliance
with the current standards and regulations. The following figure illustrates the minimum equipment needed by the installer.
5.4 Tools and materials
1) Gearmotor
2) Control panel
3) Frequency card
4) Antenna
5) Flashing light
6) Keyswitch
7) Photocells
8) Electric cable junction box
9) Mechanical endstops
10)Transmitter
5.3 Standard installation
