Pag.
2 - Manual code:
119D U 64 ver.
3 05/2013 © CAME cancelli automatici s.p.a. - The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
4.1 Gate Operator
4 Description
2.1 Intended use
1 Legend of symbols
This symbol tells you to read the section with particular care.
This symbol tells you that the sections concern safety issues.
This symbol tells you what to say to the end-user.
2 Intended use and restrictions
The F7000/F7001E gearmotor is engineered to power swing gates in homes and condominiums.
Any use, other than that above described and, any installations other than those described in this manual, are forbid-
den.
3 Reference Standards
“IMPORTANT INSTALLATION, SAFETY INSTRUCTIONS”
“CAUTION: IMPROPER INSTALLATION MAY CAUSE SERIOUS DAMAGE, FOLLOW ALL INSTALLATION INSTRUCTIONS CAREFULLY”
“THIS MANUAL IS ONLY FOR PROFESSIONAL OR QUALIFIED INSTALLERS”
2.2 Limits to use
This product is engineered and manufactured by CAME CANCELLI AUTOMATICI S.p.A. and complies with current safety regulations.
Swing gate operator with articulated transmission arm.
Models:
F7001 = 230 V AC self-locking operator.
F7001E = 230 V AC irreversibile gearmotor with encoder.
4.2 Technical features
Motor power supply: 230 V AC
Max draw.: 1,4 A
Power: 160 W
Max Torque: 180 Nm
Opening time (90°): 18 s
Duty cycle: 30%
Protection rating: IP54
Weight: 9,8 kg
Came Cancelli Automatici is ISO 9001 and ISO 14001 Quality and Environmentally certified. Came entirely designs and manufactures
its products in Italy.
The product in question compliant to the following legislation: see Declaration of Compliance.
Gate leaf length 1 m 1,5 m 2 m 2,3 m max
Gate leaf weight 300 kg max 250 kg 215 kg 200 kg
Opening 110° max
