F30 Opening slow-down speed 15 = Minimum speed / … / 40 = Maximum speed.
Setting the boom opening slow-down speed, calculated as a percentage.
⚠
Warning: the speed parameter fi elds vary according to the type of boom:
- for 2 m booms with a joint, set the slow-down speed percentage from 20 to 40;
- for 4 m booms, set the speed percentage from 20 to 30.
- for booms between 6 m and 8 m, set the slow-down speed percentage from 15 to 40.
F31 Closing slow-down speed 15 = Minimum speed / … / 40 = Maximum speed.
Setting the boom closing slow-down speed, calculated as a percentage.
⚠
Warning: the speed parameter fi elds vary according to the type of boom:
- for 2 m booms with a joint, set the slow-down speed percentage from 20 to 40;
- for 4 m booms, set the speed percentage from 20 to 30.
- for 6 m booms, set the slow-down speed percentage from 15 to 30;
- for 8 m booms, set the slow-down speed percentage from 15 to 20.
F33 Calibration speed 20 = 20% of travel (minimum) / … / 40 = 40% of travel (maximum)
Setting the boom travel automatic-calibration speed, calculated as a percentage
F34 Travel sensitivity 10 = maximum sensitivity / … / 100 = minimum sensitivity(default)
Adjusting obstruction detection sensitivity during travel.
F35 Slow-down sensitivity 10 = maximum sensitivity / … / 100 = minimum sensitivity(default)
Adjusting obstruction detection sensitivity during slow-down.
F37 Opening slow-down point 40 = 40% of travel/ … / 60 = 60% of travel
Adjusting the starting point of opening slow-down for the boom as a percentage of the total travel.
Warning! The percentage varies depending on the type of boom:
- for booms with a joint, between 2 m and 4 m, set the percentage from 40 to 60;
- for booms between 6 m and 8 m, set the percentage from 60 to 70.
F38 Closing slow-down point 20 = 20% of travel/ … / 75 = 75% of travel
Determining the starting point of closing slow-down, as a percentage of the total travel.
Warning! The percentage varies depending on the type of boom:
- for 2 m booms with a joint, set the speed percentage from 20 to 40;
- for 4 m booms, set the percentage from 40 to 60;
- for 6 m booms, set the percentage from 60 to 70;
- for 8 m booms, set the percentage from 65 to 75.
F49 Enabling serial connection 0 = Deactivated (default) / 1 = Paired/ 2 = Alternate
To enable paired or alternate operation.
F50 Save data 0 = Deactivated (default) / 1 = Activated
To save users and system settings in the memory roll.
 This function only appears if a memory roll has been inserted on the panel.
F51 Read data 0 = Deactivated (default) / 1 = Activated
To load the data saved in the memory roll.
 This function only appears if a memory roll has been inserted on the panel.
F52 Parameters transfer to paired/alternate mode 0 = Deactivated (default) / 1 = Activated
To load parameters from the MASTER barrier to the SLAVE barrier.
 This function only appears if function F 49 is set to PAIRED or ALTERNATE operation.
F60 Sleep mode
To reduce the energy consumption of the photocells in stand-by.
F61 Pre-fl ashing 0 = during opening and closing (default) / 1 = only during closing / 2 = only during opening
After an opening or closing command is given, the fl ashing light connected to 10-E1 fl ashes before the barrier begins to move.
For information on adjusting the time, see function F 21.

CAME GARD 8 SERIES Specifications

General

Model	GARD 8 SERIES
Type	Automatic Barrier
Motor voltage	24 V DC
Power	300 W
Operating temperature	-20°C to +55°C
Protection rating	IP54
Input Voltage	230 V AC
Output Voltage	24 V DC
Protection Degree	IP54
Power supply	230 V AC
Opening time	4 to 8 seconds
